Cámara domo de velocidad analógica IR DarkFighter de 4 pulgadas, 2 MP, 25 aumentos
Especificaciones
| Cámara | Detalles |
|---|---|
| Sensor de Imagen | 1/2.8" Progressive Scan CMOS |
| Máxima Resolución | 1920 × 1080 |
| Iluminación Mínima | Color: 0.005 Lux @(F1.6, AGC ON), B/W: 0.001 Lux @(F1.6, AGC ON), 0 lux with IR |
| Velocidad de Obturación | PAL: 1/1 s to 1/10,000 s, NTSC: 1/1 s to 1/10,000 s |
| Día y Noche | IR cut filter |
| Zoom | 25× optical, 16 × digital |
| Lente | |
| Longitud Focal | 4.8 mm to 120 mm, 25 × optical |
| FOV | Horizontal FOV: 57.6° to 2.5° (wide to tele) |
| Enfoque | Auto, semi-auto, manual |
| Apertura | F1.6 to F3.5 |
| Velocidad Del Zoom | Approx. 3.2 s (optical, wide to tele) |
| Iluminador | |
| Tipo de Luz Suplementaria | IR |
| Rango de Luz Suplementaria | Up to 100 m |
| PTZ (Pan-Tilt-Zoom) | |
| Rango de Movimiento (Pan) | 360° endless |
| Rango de Movimiento (Tilt) | -15° to 90° (auto flip) |
| Velocidad de Movimiento Horizontal (Pan) | Pan manual speed: 0.1° to 80°/s, Pan preset speed: 80°/s |
| Velocidad de Vertical (Tilt) | Tilt manual speed: 0.1° to 80°/s, Tilt preset speed: 80°/s |
| Proporcional Pan | Rotation speed can be adjusted automatically according to zoom multiples |
| Preajustes | 256 |
| Escaneo de Patrulla | 10 patrols, up to 32 presets for each patrol |
| Patrón de Escaneo | 5 patterns, record time over 10 minutes for each scan |
| Acción del Parque | Preset/Patrol/Pattern/Pan Scan/Tilt Scan/Panorama Scan/Day Mode/Night Mode/None |
| Pantalla de Estado de PTZ | Yes |
| Tarea Programada | Preset/Patrol/Pattern/Pan Scan/Tilt Scan/Panorama Scan/Day Mode/Night Mode/Zero Calibration/None |
| Memoria de Apagado | Yes |
| Vídeo | |
| Frame Rate | 50 Hz: 25 fps @(1920 × 1080), 60 Hz: 30 fps @(1920 × 1080) |
| Red | |
| Protocolos | UTC protocol (or HIKVISION-C protocol in previous DVR) |
| Imagen | |
| Configuración de Imagen | AGC, white balance |
| Wide Dynamic Range (WDR) | ≥ 120 dB |
| Image Stabilization | EIS |
| Mejora de la Imagen | BLC, HLC, 3D DNR |
| Máscara de Privacidad | 8 programmable privacy masks |
| Enfoque Regional | Yes |
| Interfaz | |
| Salida de Vídeo | Switchable TVI/AHD/CVI/CVBS video output, (NTSC or PAL composite, BNC) |
| RS-485 | Half-duplex mode, Self-adaptive HIKVISION, Pelco-P, Pelco-D protocol |
| General | |
| Alimentación | 12 VDC, max. 20 W (IR: 7 W) |
| Dimensión | Ø 164.5 × 295 mm (Ø 6.47" × 11.61") |
| Operating Condition | -30° C to 65° C (-22° F to 149° F), Humidity 90% or less |
| Idioma | English |
| Certificaciones | |
| Protección | IP66 (outdoor dome), TVS 4,000 V lightning protection, surge protection and voltage transient protection |
